Hydraulic Machine Vice HV 150

+3

+2

Hydraulic Machine Vice HV 150

Product Details

Click/Tap here for full Sec list PDF

Made In Taiwan

Suitable For Vertical Machine Center, Milling Machine
JAW Squareness 0.02mm
Both JAW Plate Parallelism 0.015mm
Parallelism Of Body Bottom Face And JAW Slideway 0.01mm
Parallelism Of Guide Block Side Of Bottom Face And Fixed JAW Clamp Face 0.01mm

HYDRAULIC MACHINE VISE (BUILT-IN TYPE) ★ Pressure bust system. Patent number: M314660

Key Points：

Most suitable for vertical machine center, milling machine.
Vise body is made of high quality ductile cast iron resists bending.
Pressure system for maximum clamping pressure with minimum force.
3 clamping ranges design: Quick to change and easy to operate.

MODEL	A	B	C	D	E	F	G	H	I	J	K	L	Clamping Range			Clamping Force	Weight(kg)
MODEL	A	B	C	D	E	F	G	H	I	J	K	L	X	Y	Z	Clamping Force	Table	Disk Rotary
HV-100	105	36	170	525	440	135	170	95	58	80	95	147	0-57	55-114	112-170	2500kg	21	>7
HV-130	130	48	220	670	550	175	207	120	70.5	97	107	195	0-73	>72-146	145-220	3000kg	38	>8
HV-150	150	53	300	800	620	182	225	135	82.5	116	117	210	0-100	98-200	198-300	4500kg	53	11
HV-200	200	62	300	900	680	260	280	162	100	160	150	260	0-100	99-200	198-300	8000kg	95	13
